Wireless Outdoor Temperature Sensors & Monitoring Systems

For outdoor industrial environments, a minimum IP66 rating is recommended to protect against dust ingress and powerful water jets. Several products in this category, including the FLIR A50/A70, FLIR A40, and Seek G300, are rated IP67, providing full dust protection and resistance to temporary water immersion, making them suitable for harsh outdoor conditions.

Most professional-grade thermal cameras in this category achieve ±2°C or ±2% of reading accuracy, whichever is greater. This applies to FLIR A-series and Seek G300 cameras under standard ambient conditions of 15°C to 35°C. The Seek G300 specifies ±5°C for its target temperature range of 5°C to 100°C. Accuracy is influenced by ambient temperature, target emissivity, and installation distance.

Yes. Systems equipped with the iTL Cloud Monitoring Solution send event-based alerts via text message, voice call, and email immediately upon detecting a threshold breach. The iTL Gateway signals the cloud server independently of the data update rate, ensuring alarm response is near-instantaneous locally. On-camera digital outputs also support direct alarm relay to PLCs and external systems.

These systems support a wide range of industrial and IT protocols including Modbus TCP, EtherNet/IP, MQTT, ONVIF, GigE Vision, GenICam, REST API, RTSP, HTTP/HTTPS, and Profinet. Wi-Fi (IEEE 802.11a/b/g/n) and cellular LTE are available for wireless connectivity, enabling integration with SCADA, HMI, VMS, and cloud IoT platforms without additional middleware.

Measurement ranges vary by model. The FLIR AX8 covers -10°C to 150°C, the Seek G300 covers -20°C to 550°C, and the FLIR A400/A500/A700 series can measure up to 2000°C on the A700 model. The IRSX camera supports an optional high-temperature range up to 1,200°C. This breadth makes the portfolio suitable for applications from electrical cabinet monitoring to molten metal processing.

No. The iTL Cloud Monitoring Solution requires no software installation. Users simply mount the camera, connect the iTL Gateway to the same network, and access the iTL Studio platform from any internet-connected device. Camera configuration for most FLIR and Seek models is handled via a standard web browser interface. FLIR Research Studio software is included with Science Kit models for offline analysis workflows.
