Optris Xi 80 Infrared Camera
$1,200.00
Guaranteed safe & secure checkout
We also accept ACH/wire transfer, checks, and purchase orders.
Compact Spot Finder IR Camera
The newly developed Optris Xi 80 combines the benefits of infrared cameras and infrared thermometers.
A full 80×80 thermal image eliminates the hunt for the hot spot and tedious positioning required with single spot temperature sensors. The integrated spot finder function will identify the hottest (or coldest) spot in the image and automatically communicate these measurements without an external PC.
Highlights:
- Small sized rugged camera with motorized focus
- Distance-to-spot-size ratio up to 190:1
- Autonomous operation with automatic spot finder
Please note: This item has an average lead time of 4-6 weeks for delivery.
We’re here to help you!
We are an official partner!
20+ years experience!
Call us to learn more!
Description
The newly developed Optris Xi 80 combines the benefits of infrared cameras and infrared thermometers.
A full 80×80 thermal image eliminates the hunt for the hot spot and tedious positioning required with single spot temperature sensors. The integrated spot finder function will identify the hottest (or coldest) spot in the image and automatically communicate these measurements without an external PC.
A wide range of optics including the new 80° lens equips the Optris Xi 80 to collect and analyze temperature information over a wide target area. The affordable pricing for this unit makes it a realistic alternative to replace existing spot temperature sensors or for OEM applications.
Highlights:
- Small sized rugged camera with motorized focus
- Distance-to-spot-size ratio up to 190:1
- Autonomous operation with automatic spot finder
Areas of Application for the Spot Finder Xi 80:
The Xi 80 is a fusion between a robust, compact pyrometer and an advanced IR camera. The autonomous operation with automatic spot finder function as well as the direct analog output and the affordable price make up a perfect match for the OEM use of the rugged industrial imager.
Included:
- Process imager Xi
- USB cable (1 m)
- Cable for output/input (1 m) incl. terminal block
- Mounting bracket with nut
- Software package Optris® PIX Connect
Specifications
| Technical Specifications – Optris Xi 80 | |
|---|---|
| Optical resolution | 80 x 80 pixels |
| Detector | FPA, uncooled (34 µm x 34 µm) |
| Spectral range | 8 – 14 µm |
| Temperature ranges | –20 °C … 100 °C (–4 °F … 212 °F) 0 °C … 250 °C (32 °F … 482 °F), 150 °C … 900 °C1) (302 °F … 1652 °F)1) |
| Frame rate | 50 Hz |
| Optics (FOV) | 12° (f = 12.7 mm [0.50 in]) 30° (f = 5.1 mm [0.20 in]) 55° (f = 3.1 mm [0.12 in]) 80° (f = 2.3 mm [0.09 in]) |
| Focus | Motorized focus |
| Optical resolution D:S | 190:1 (12° optics) |
| Direct Output/Input | 1x analog output (0/4-20 mA) / 1x input (analog or digital); electrically isolated |
| Thermal sensitivity (NETD) | 100 mK |
| Accuracy | ±2 °C or ±2 % (±3.6 °F or ±2 %), whichever is greater |
| PC interface | USB 2.0 / Ethernet (100 Mbit/s) / PoE / RS 4852) |
| Process interface (PIF), industrial | 3x analog outputs (0/4–20 mA or 0–10 V) and 3x alarm outputs (relais) / 3x inputs (analog or digital) / fail-safe (LED and relay); stackable up to 3 PIFs; electrically isolated |
| Cable length (USB) | Ethernet / RS485: 20 m (65.6 ft), (extendable up to 100 m [328.1 ft]) USB: 1 m (3.3 ft) (standard), 3 m (9.8 ft), 5 m (16.4 ft) |
| Ambient temperature | 0 °C to 50 °C (32 °F to 122 °F) |
| Enclosure (size / rating) | Ø 36 mm x 90 mm (Ø 1.42 in x 3.54 in); (M30x1 thread) / IP 67 (NEMA 4) |
| Weight (without mounting bracket) | 201 – 210 g, (7.1 – 7.4 oz) depending on lens |
| Shock / Vibration | IEC 60068-2-27 (25G and 50G) / IEC 60068-2-6 (sinus shaped), IEC 60068-2-64 (broadband noise) |
| Power supply | 5-30 V DC / PoE / USB |
| Scope of supply | • Process imager Xi • USB cable (1 m [3.3 ft]) • Cable for output/input (1 m) incl. terminal block • Mounting bracket with nut • Software package optris PIX Connect |
- Accuracy statement effective from 150 °C
- Direct out- and inputs are not available when using the RS485 interface.
